Detailed Introduction
3.2T DR8
3dB-bandwidth: 110 GHz
Insertion loss: < 14 dB (Including coupling loss)
Half-wave voltage: < 1.5 V (differential)
DC-ER: > 25 dB
Differential (support AC or DC coupling) or single-ended
1.6T DR8/800G DR4
3dB-bandwidth: 70 GHz
Insertion loss: < 14 dB (Including coupling loss)
Half-wave voltage: < 2 V (differential)
DC-ER: > 25 dB
Differential (support AC or DC coupling) or single-ended
1.6T/800G ZR Coherent PDMIQ
3dB-bandwidth: 70 GHz
Insertion loss: < 7 dB
Half-wave voltage: < 4.5 V (differential)
DC-ER: > 25 dB
Intensity Modulator Die Chip
3dB-bandwidth: 110 GHz
Insertion loss: < 5 dB
Half-wave voltage: < 3.0 V
DC-ER: > 20 dB
